          Banana Pi / BPI-M1 Super (RK3528) (4G LPDDR4x+32G eMMC)

          Powerful SBC'S

          The Banana Pi BPI-M1 Super is your ultimate single-board computer for IoT, DIY projects, media centers, and educational applications. Featuring a quad-core processor, extensive connectivity options, and support for Linux, Android, and other open-source platforms, this compact yet powerful SBC delivers exceptional performance and versatility. Whether you're a developer, hobbyist, or educator, the BPI-M1 Super is designed to meet your needs with efficiency and innovation.

          Unleash your creativity and take your projects to the next level with the Banana Pi BPI-M1 Super.

          Specifications: Key Parameter

          SoCRockchip RK3528
          CPURK3528 Quad-core Cortex-A53
          GPUARM Mali-450 GPU

          VPU/Decoding:

          • Hardware Decoding: Supports 60fps playback of 4K ultra-high-definition video with up to 10-bit pixels. Supports video standards including H.265, H.264, AVS2, etc.

          • Hardware Encoding: Supports 60fps capture of 1080p high-definition video. Supports H.265 and H.264 encoding.

          RAM
          Flash

          Operating System:

          • Officially Supported by Rockchip: Android 9.0_box, Debian11, Buildroot

          • Third-party Support: Armbian

          Dimensions92mm × 62mm x 14.6mm

          Network

          1x 2.5G Ethernet port

          1x Gigabit Ethernet port

          Onboard IEEE 802.11a/b/g/n/ac/ax WIFI6 and BT5 (rtl8852bs)

          Video Output

          1x HDMI OUT2.0b, supports 4K@60fps

          Audio

          1x HDMI audio output

          1x HP-OUT audio output

          USB Ports

          2x USB2.0, supports High-Speed (480Mbps), Full-Speed (12Mbps), and Low-Speed (1.5Mbps) modes

          1x USB Type-C 2.0, supports OTG, supports high-speed (480Mbps), full-speed (12Mbps) and low-speed (1.5Mbps) modes

          40-pin

          Compatible with Raspberry Pi 40-pin GPIO, supports various accessory peripherals

          Supports UART/SPI/I2C/I2S/PWM/5V Power/3.3V Power

          Others

          1x 5V fan interface

          1x battery input connector for low-power RTC chip HYM8563TS

          2x LED lights, green light starts blinking when system is normal, red light controlled by user

          Power

          Supports USB Type-C, 9V/2A, 12V/2A, 15V/2A

          1x Reset button, supports reboot

          1x Maskrom button, supports entering maskrom burning mode

          1x PWRON botton

          System

          Officially Supported by Rockchip: Android 9.0_box, Debian11, Buildroot

          Third-party Support: Armbian, Istoreos

          Dimensions

          92 mm x 62mm

          Operating Temperature

          0℃ ~ 80℃
